Are you having difficulties comprehending what your Subaru dashboard lights signify? This could be daunting for someone who is new to driving. However, once you’re in the driver’s seat, you’ll become familiar with the significance of every light on your Subaru dashboard.
Need tools for your project? Toolbox, a tool rental marketplace, might be worth a look.
In Subaru vehicle models, red dashboard lights require immediate attention. Driving your car with such lights on can be fatal. Yellow lights are warnings that an issue needs to be addressed soon. Lastly, there are blue or green lights, which are informational.
We will highlight some Subaru dashboard lights that every driver should know. Read on for details!
Read this next: Subaru Outback Years to Avoid
20 Common Subaru Dashboard Lights
Rear Differential Temperature Indicator
This warning light is usually available on the heavy-duty Subaru STI model. With red letters R. DIFF TEMP, it alerts you that the rear end temperature is excessively high. This light comes on if the third members are overworked and overheating. They are made of high-tensile strength metal but can be easily affected by heat.
If the rear differential light comes on when driving, pull over and let it cool before continuing again. If the light comes on again after cooling, call for immediate assistance. Don’t continue driving.
READ MORE: Toyota Dashboard Symbols And Meanings
All Wheel Drive Trouble Indicator
An All-Wheel Drive can be amber and comes on when there is a problem with the AWD system and may fail to function appropriately. It illuminates on your dashboard if there is a low tire pressure or your final drive speed is not within the defined limits. There may be other causes, but those are rare to occur.
If this yellow AWD light comes on, you need to check your car. You have to be sure of the cause and have it corrected.
Related article: Are Subarus Expensive To Fix?
EV Charging Indicator
This symbol is used in electric and hybrid vehicles. It may appear like a green, amber, or red electric plug on the dashboard. In some models, it will be the green letters EV. Whichever the case, this indicator light shows that the battery is being charged and will turn off once the charge is complete.
Read next:
> Best Year Subaru Impreza
> Subaru Impreza Years to Avoid: A Comprehensive Overview
> Subaru Impreza Problems: Too Much To Handle?
Frost Or Cold Warning Or Snow Mode Indicator
When activated, it may indicate that the vehicle is on a snow mode or you are being warned of a frost or freeze. For the latter, an amber symbol showing snowflakes or ice crystals appears on the dashboard. That usually occurs when the outside temperature falls to the freezing point, about 40 degrees Fahrenheit. A further drop in temperature will turn the indicator red, showing that the condition is critical.
Keep reading:
> Subaru Legacy Years To Avoid
> Best Year Subaru Legacy
> Subaru Legacy Problems
Automatic Headlight Dimmer Or Malfunction Indicator
Automatic headlight dimmer or high beam assistant symbols can be blue or green. They are shown with straight horizontal lines from the headlamp. If an auto mode is activated, the letter A or AUTO appears adjacent to the symbol. The vehicle system automatically dims light if the headlights of an oncoming vehicle are detected.
If there is a malfunction with the automatic headlamp dimmer, an exclamation mark appears next to the symbol. You should resolve the issue if you intend to use this functionality.
READ MORE: Why is my Dodge truck A/C switch stuck on defrost?
Traction And Active Traction Control Indicators
If the traction control system is on and working appropriately, green letters TRAC, ACTIVE TRAC, or A-TRAC appear. If there is a problem with the system, the color turns yellow. The master warning light may accompany this.
Yellow or amber symbols of TCSS OFF, TRAC OFF, or TCS OFF mean the traction system has been turned off. But if these lights persist when the switch is still on, there is a malfunction. Take your vehicle to the mechanic for diagnosis and repair.
Reverse Automatic Braking (RAB) Indicators
Automatic reverse brake indicators are amber warning lights with the acronym RAB illuminated on the dashboard. If it appears, it shows the system has an issue that a qualified auto mechanic should resolve. It can sometimes light as RAB OFF, which means the automatic reverse brake is off. When this appears when the switch is on, it also indicates a fault.
Read next: Are Subaru WRX Reliable? Yes and No (Here’s Why)
Keyless Ignition Detection Indicator
Different picture symbols are used to show that an electronic key is nearby. This symbol is available in keyless ignition or push-button start vehicles. It illuminates when the wireless key is detected, and the engine can be started by pushing the button.
A keyless ignition indicator is usually green, amber, or red key. But in some models, it is a key or a padlock with waves radiating from it. If it turns red and has an exclamation mark, the key is not detected. That is probably because the internal battery is drained and needs replacement. A yellow or amber one shows a fault.
How Does The Forester Fare?
> Best Years for Subaru Forester
> Forester Years to Avoid
> Subaru Forester Problems: Too Much To Handle?
Lane Departure Warning Indicator
The lane departure alert or warning is available in some Subaru models. The indicator is usually a car with lane markings on both sides. If lane departure is detected, the car in the symbol veers off the lane. It only shows up when the road markings are visible to the sensors on the vehicle.
If the system is off, the word OFF appears below the symbol. And if there is a fault, an exclamation mark appears.
READ MORE: Engine Hot AC Off: What Does It Mean And How To Fix It?
Collision Warning System and Malfunction Indicator
Pre-collision or Crash System (PCS), Forward Collision Warning (FCW) system, or Collision Mitigation Brake System (CMBS) refers to the same thing. It is a safety feature installed in most cars to reduce accident severity. The system uses a camera or radar to detect a possible collision and intelligently change suspension and brake settings.
Those acronyms listed above or two cars coming head-on can symbolize the indicator. The word OFF is added to the symbol if you turn this system off. And if there is a fault, an exclamation mark is added instead.
Low Speed, Grade, And Terrain Assist Indicator
This symbol is common in many four-wheel-drive vehicles. It is shown by an SUV vehicle on a rugged or steep surface, while some models show it with a speedometer. When activated, a green light. It helps drivers on uneven terrains by balancing brake and throttle to avoid slipping or getting stuck.
EV Mode Operation Indicators
Drivers can switch the vehicle to use only the electric motor to power it, provided the battery is capable. When activated, a green EV symbol lights on the dashboard. If there is a clock in the top-right corner, it shows that the high-voltage battery is being saved.
Subaru Intelligent Drive system has other EV mode operation indicators. They appear as I or S in square braces. The I shows intelligent mode, which allows the system to optimize battery usage. The S indicates sports mode, where the driver controls the battery usage.
Related: Subaru Starter Replacement Cost: What You Need to Know
Hybrid Battery Overheat Indicator
If the temperature of an inverter with converter assembly is high, an amber light appears. The symbol is a household battery with wavy lines coming from it. These are heat waves, indicating that the battery is overheating.
Active, Adaptive, And Cornering Light Malfunction Indicator
The adaptive cornering headlight technology allows your headlight to turn when you are negotiating bends to illuminate the road ahead. The system reads the steering angle and the vehicle speed to adjust the headlights automatically. If there is a problem with this adaptive-front-lighting system, the malfunction indicator lights up. It is similar to the headlamp symbol, but it is vertical and has a curved line with arrows on both sides.
Blind Spot Warning and Monitoring Indicator
Blind Spot Monitor or Blind Spot Detection System informs you if a vehicle is detected in the blind spot region. It is symbolized by two cars where one beams at the other. If there is a problem with this system, the symbol appears with an exclamation mark. But when you turn off the system, the word OFF appears with the symbol.
Headlamp Indicator
Green straight horizontal beams show this from an old-style headlamp. It comes on when the headlamp switch is activated and working appropriately. If the lamp is out, an exclamation light appears.
Hybrid Ready Indicator
This symbol is for hybrid vehicles. It informs the driver that the hybrid is ready to move. The symbol is a blue READY inscribed in a rectangle or a green car with a double-headed arrow below it. It is usually activated when the key fob is present, or when the start/power button is pressed when the vehicle is parked.
Driver Monitoring System Indicators
Driver monitoring indicators appear as an eye in a box with sides broken by lines. It illuminates green when the system is engaged and working as expected. If there is a fault, a yellow indicator with a dark background comes on instead. But if it is off, the OFF word appears with the yellow symbol.
READ MORE: Best ATV Battery-Top picks for ATV drivers (Review and buying guide)
Electric Side Step or Auto Running Board Indicator
The symbol appears on the dashboard when the electric side step is active, which is done by opening the sliding side doors found in minivans and vans. Its symbol is an image of a rear view of a van. It also appears as the side of the car with an intrusion and a double-headed arrow. If the light remains on, there is an obstruction. And if it flashes, a fault has occurred.
Extended Range EV Mode Indicators
As the name suggests, these symbols are found in electric or hybrid vehicles. They usually appear in grayscale in different vehicle models. The first EV mode indicator symbol looks like a locked household battery. It is activated to help maximize EV miles and fuel efficiency and is recommended for highway speeds.
The other mode is symbolized by a household battery with a mountain beside it. Your car will activate the indicator if the trip is to go through mountainous terrains for better climbing performance. You should change to this mode at least 20 minutes before you start climbing to recharge the battery.
Red Warning Lights
| Dashboard warning light | Name | Message |
|---|---|---|
 | Charging System Trouble Light | Serious Charging System problem. The vehicle should be brought to a complete stop as quickly as possible or the vehicle may simply stop running. |
 | Charging System Trouble Light | The vehicle’s hybrid battery must be serviced by your dealer or qualified service professional as soon as possible. |
 | Brake Trouble Light | A serious problem with the brakes. The light will also be on when the hand, or emergency, brake is engaged. |
 | Brake Trouble Light | A serious problem with the brakes. The light will also be on when the hand, or emergency, brake is engaged. |
 | Brake Trouble Light | A serious problem with the brakes. The light will also be on when the hand, or emergency, brake is engaged. |
 | Brake Trouble Light | A serious problem with the brakes. The light will also be on when the hand, or emergency, brake is engaged. |
 | Brake Trouble Light | A serious problem with the brakes. The light will also be on when the hand, or emergency, brake is engaged. |
 | Brake Trouble Light | The car should be pulled over as soon as possible to allow them to cool. If they stay hot, the brake fluid will get hot and boil, at which point brake pressure will be non existent. |
 | Oil Warning Lights | Without the wavy line, your engine is telling you that the oil pressure is low. |
 | Oil Warning Lights | A wavy line below the oil can indicates the oil level is low. |
 | Oil Warning Lights | If it is seen on the instrument panel, pull over and shut down the engine as soon as possible to allow it to cool down. |
 | Temperature Warning Indicators | The engine temperature is too high. Should stop the vehicle and turn off the engine. Turning on the heater to the highest setting will remove some of the heat as well. |
 | Power Steering Trouble Light | |
 | Power Steering Trouble Light | Pull over as soon as possible and shut down the engine and restart it. |
 | SRS Air Bag Indicator | A problem exists with one of the many airbags in the vehicle, which should be taken to the dealer or authorized service center as soon as possible. |
 | SRS Air Bag Indicator | A problem exists with one of the many airbags in the vehicle, which should be taken to the dealer or authorized service center as soon as possible. |
 | SRS Air Bag Indicator | Warn of a failure in one of the air bags, which can only be repaired by your dealer or authorized service center. |
 | Seat Belt Reminder Indicator | The indicators simply want you to put on your seat belt. |
 | Seat Belt Reminder Indicator | Showing two belted occupants, indicates either the driver or passenger is unbuckled. Regardless, the indicators simply want you to put on your seat belt. |
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. |
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. |
 | Security and Immobilizer System Indicator | Indicates a malfunction in the security system. |
 | Door Ajar and Other Open Indicator | Close the door, trunk lid, rear hatch, hood, or whatever is shown as open as soon as possible. |
 | Door Ajar and Other Open Indicator | The ignition is on and Driver’s Door is the one open. So long as the vehicle is not in gear, there should be nothing to be concerned about. |
 | Door Ajar and Other Open Indicator | Indicate that the Trunk Lid, Hatch or Tailgate is open or not properly latched. |
 | Door Ajar and Other Open Indicator | Indicate that the Trunk Lid, Hatch or Tailgate is open or not properly latched. |
 | Door Ajar and Other Open Indicator | Indicate that the Trunk Lid, Hatch or Tailgate is open or not properly latched. |
 | Door Ajar and Other Open Indicator | Indicate that the Trunk Lid, Hatch or Tailgate is open or not properly latched. |
 | Hood Ajar indicators | Be sure the hood is closed and/or that nothing is preventing the hood from fully closing. |
 | Keyless Ignition Detection Indicator | Indicates that the key is not detected. |
 | Transmission Oil Temperature Indicators | The oil temperature in the transmission is too high, which risks transmission failure. |
 | Transmission Oil Temperature Indicators | The oil temperature in the transmission is too high, which risks transmission failure. |
 | Transmission Oil Temperature Indicators | A transmission in a number of instances. Again, pull over and allow the transmission to cool down or there is a risk of failure. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | The brake is engaged and the ignition on. |
 | Electric Park Brake and Fault Indicator | The brake is engaged and the ignition on. |
 | Tire Pressure Monitoring System Indicator | The pressure in a tire can be very, very low and not result in a large change in the handling of some vehicles. |
| Rear Differential Temperature Indicator | Indicates that the oil in the rear differential is too hot. | |
| All Wheel Drive Trouble Indicators | A problem with an All Wheel Drive system. | |
 | EV Charging Indicator | The vehicle’s main battery is being charged and will turn off when it is fully charged. |
Yellow/Orange Indicator Lights
| Dashboard warning light | Name | Message |
|---|---|---|
| Brake Trouble Light | The car should be pulled over as soon as possible to allow them to cool. If they stay hot, the brake fluid will get hot and boil, at which point brake pressure will be non existent. | |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | Service is needed. |
 | Electric Park Brake and Fault Indicator | The brake is engaged and the ignition on. |
 | Electric Park Brake and Fault Indicator | The brake is engaged and the ignition on. |
 | Electric Park Brake and Fault Indicator | The brake is engaged and the ignition on. |
 | Electric Park Brake and Fault Indicator | Indicate a fault in the system if illuminated. |
 | Oil Warning Lights | An admonition to check the oil. If the oil level is good, the engine needs servicing as soon as possible as an oil pump failure is likely and will lead to serious engine damage. |
 | Oil Warning Lights | An admonition to check the oil. If the oil level is good, the engine needs servicing as soon as possible as an oil pump failure is likely and will lead to serious engine damage. |
 | Oil Warning Lights | The engine’s RPM has been reduced. Low oil pressure can result in serious engine damage, even at reduced RPMs, so have the engine serviced as soon as possible. |
 | Temperature Warning Indicators | The engine temperature is too high. Stop the vehicle and turn off the engine. Turning on the heater to the highest setting will remove some of the heat as well. |
 | Temperature Warning Indicators | Fuel having entered the engine oil. Run the engine until warm to allow the fuel to evaporate. Also, avoid running at a high rpm as well. |
 | Power Steering Trouble Light | |
 | SRS Air Bag Indicator | A problem exists with one of the many airbags in the vehicle, which should be taken to the dealer or authorized service center as soon as possible. |
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. |
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. |
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. |
 | Sunroof Open indicators | Close the sunroof if you wish. |
 | Fuel, Low Fuel, and Fuel Sensor Indicators | |
 | Fuel, Low Fuel, and Fuel Sensor Indicators | |
 | Fuel, Low Fuel, and Fuel Sensor Indicators | |
 | Low Windshield Washer Fluid Indicators | Fill the windshield washer fluid reservoir as soon as possible. |
 | Low Windshield Washer Fluid Indicators | Fill the windshield washer fluid reservoir as soon as possible. |
 | Low Windshield Washer Fluid Indicators | Fill the windshield washer fluid reservoir as soon as possible. |
 | Low Windshield Washer Fluid Indicators | Fill the windshield washer fluid reservoir as soon as possible. |
 | Frost or Cold Warning or Snow Mode Indicato | The outside temperature drops to within a few degrees of freezing (about 40°F). |
 | Frost or Cold Warning or Snow Mode Indicato | Indicate cold weather and the possibility of frost on the roadway. |
 | Frost or Cold Warning or Snow Mode Indicato | Indicate cold weather and the possibility of frost on the roadway. |
 | Check Engine Light | |
 | Check Engine Light | |
 | Check Engine Light | Check that the gas cap is installed and properly tightened (make sure it clicks at least once). |
 | Check Engine Light | Indicates a fault in an emissions related electronic system. |
 | Check Engine Light | Meant to convey a likely issue with the engines electrical system. |
 | Check Engine Light | Meant to convey a likely issue with the engines electrical system. |
 | Check Engine Light | Meant to convey a likely issue with the engines electrical system. |
 | Check Engine Light | A minor engine fault has been detected |
 | Check Engine Light | |
 | Keyless Ignition Detection Indicator | Indicate the presence of an electronic key in a push button or, ironically, keyless start, or keyless ignition, vehicle. |
 | Keyless Ignition Detection Indicator | Indicate the presence of an electronic key in a push button or, ironically, keyless start, or keyless ignition, vehicle. |
 | Keyless Ignition Detection Indicator | Indicate the presence of an electronic key in a push button or, ironically, keyless start, or keyless ignition, vehicle. |
 | Keyless Ignition Detection Indicator | Indicate a weak fob battery |
 | Keyless Ignition Detection Indicator | Indicates that the fob is not detected or has been removed from the vehicle. |
 | Keyless Ignition Detection Indicator | Indicates that the fob is not detected or has been removed from the vehicle. |
 | Keyless Ignition Detection Indicator | The fob is detected but that the battery in the fob is low and should be replaced. |
 | Keyless Ignition Detection Indicator | Replace the battery as soon as possible. They do NOT use AA or AAA batteries! |
 | Keyless Ignition Detection Indicator | Replace the battery as soon as possible. They do NOT use AA or AAA batteries! |
 | Keyless Ignition Detection Indicator | Replace the battery as soon as possible. They do NOT use AA or AAA batteries! |
 | Keyless Ignition Detection Indicator | Get to get into and start your vehicle only if the correct device is present, has a working battery and is not interfered with by other electronics |
 | Keyless Ignition Detection Indicator | Get to get into and start your vehicle only if the correct device is present, has a working battery and is not interfered with by other electronics |
 | Slip, Stability Control and Fault Indicator | When a vehicle detects slippery conditions, its stability or traction control system is activated. The light will flash, irregularly in some vehicles, indicating that the system is doing its work, helping to keep the vehicle in control. |
 | Slip, Stability Control and Fault Indicator | When a vehicle detects slippery conditions, its stability or traction control system is activated. The light will flash, irregularly in some vehicles, indicating that the system is doing its work, helping to keep the vehicle in control. |
 | Slip, Stability Control and Fault Indicator | When a vehicle detects slippery conditions, its stability or traction control system is activated. The light will flash, irregularly in some vehicles, indicating that the system is doing its work, helping to keep the vehicle in control. |
 | Slip, Stability Control and Fault Indicator | When a vehicle detects slippery conditions, its stability or traction control system is activated. The light will flash, irregularly in some vehicles, indicating that the system is doing its work, helping to keep the vehicle in control. |
 | Slip, Stability Control and Fault Indicator | Indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | Indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | Indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | Indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | Indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | indicates a fault in the stability control system. The vehicle will operate normally, but without the advanced control system. |
 | Slip, Stability Control and Fault Indicator | When the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | When the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | When the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | When the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | When the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | when the system is functioning properly and doing its job |
 | Slip, Stability Control and Fault Indicator | Indicates that the vehicle has detected a fault in the system. |
 | Slip, Stability Control and Fault Indicator | Indicates that the vehicle has detected a fault in the system. |
 | Slip, Stability Control and Fault Indicator | Indicates that the vehicle has detected a fault in the system. |
 | Stability Control Off Indicators | The stability control system is deactivated. |
 | Stability Control Off Indicators | The stability control system is deactivated. |
 | Stability Control Off Indicators | There is clearly a problem that should be addressed as soon as possible. |
 | Traction and Active Traction Control Indicators | Indicates the system is on and functioning or that the system has a malfunction, respectively. |
 | Traction and Active Traction Control Indicators | Indicates the system is on and functioning or that the system has a malfunction, respectively. |
 | Traction and Active Traction Control Indicators | Indicates the system is on and functioning or that the system has a malfunction, respectively. |
 | Traction and Active Traction Control Indicators | Any of these system variants is turned off using its control switch. |
 | Traction and Active Traction Control Indicators | Any of these system variants is turned off using its control switch. |
 | Traction and Active Traction Control Indicators | The traction control system is switched off |
 | Traction and Active Traction Control Indicators | The traction control system is switched off |
 | Traction and Active Traction Control Indicators | The traction control system is switched off |
 | Traction and Active Traction Control Indicators | The traction control system is switched off |
 | Traction and Active Traction Control Indicators | The traction control system is switched off |
 | Traction and Active Traction Control Indicators | The Stability Control System has been turned off and that a Traction Control Mode may be chosen to suit the driver or the conditions |
 | Traction and Active Traction Control Indicators | Indicate a malfunction in the traction control or a related Stability Control system. |
 | Traction and Active Traction Control Indicators | Indicate a malfunction in the traction control or a related Stability Control system. |
 | Traction and Active Traction Control Indicators | Indicate a malfunction in the traction control or a related Stability Control system. |
 | Traction and Active Traction Control Indicators | Indicate a malfunction in the traction control or a related Stability Control system. |
 | Tire Pressure Monitoring System Indicators | The inflation on one of the tires is reduced about 25% or more. In most cases, that will be about eight pounds |
 | Tire Pressure Monitoring System Indicators | The system needs to be reset or could mean that a tire is low as well. Regardless, the tire pressures must be checked for the sake of safety. |
 | Antilock Braking System Trouble Lights | The ABS system helps to keep the car from skidding out of control during braking in slippery or extreme braking conditions by limiting your wheels from locking up. |
 | Antilock Braking System Trouble Lights | The ABS system helps to keep the car from skidding out of control during braking in slippery or extreme braking conditions by limiting your wheels from locking up. |
 | Antilock Braking System Trouble Lights | In slippery conditions, the driver must control any tendency for the wheels to lock during braking. |
 | Antilock Braking System Trouble Lights | Indicate a problem with the 4- or All-wheel Drive system as well as the ABS System. If this is the case, one or more additional indicators will be present. Have the vehicle checked as soon as possible by a competent shop. |
 | Antilock Braking System Trouble Lights | Come on when the ABS system is simply doing its job . It does not indicate a fault |
 | All Wheel Drive Trouble Indicators | All-Wheel Drive is disengaged and the drive mechanism is switched to Front Wheel Drive for maintenance or if there is a problem with the system. |
 | All Wheel Drive Trouble Indicators | All-Wheel Drive is disengaged and the drive mechanism is switched to Front Wheel Drive for maintenance or if there is a problem with the system. |
 | All Wheel Drive Trouble Indicators | All-Wheel Drive is disengaged and the drive mechanism is switched to Front Wheel Drive for maintenance or if there is a problem with the system. |
 | All Wheel Drive Trouble Indicators | Malfunctions may be indicated by the system before a real problem is obvious, but don’t waste time. Have the system checked out as soon as possible. |
| Driver Monitoring System Indicators | Indicates that the system is turned off | |
| Driver Monitoring System Indicators | Indicates that the system is turned off | |
| Driver Monitoring System Indicators | Indicates a malfunction in the system. | |
 | Blind Spot Warning or Monitoring System | A vehicle is detected in the blind spot. |
 | Blind Spot Warning or Monitoring System | Indicated by a separate alert and text message in the instrument panel. |
 | Blind Spot Warning or Monitoring System | The option has been switched off or has malfunctioned |
 | Blind Spot Warning or Monitoring System | The option has been switched off or has malfunctioned |
 | Blind Spot Warning or Monitoring System | A vehicle is detected in the blind spot. |
 | Blind Spot Warning or Monitoring System | The assist system is inoperative and will not detect vehicles alongside your car. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | A warning chime may also be heard |
 | Lane Departure Warning Indicators | A warning chime may also be heard |
 | Lane Departure Warning Indicators | The system is turned off, |
 | Lane Departure Warning Indicators | A fault in the system. |
| Reverse Automatic Braking (RAB) Indicators | Indicates a fault in the system that will require a qualified service shop. | |
| Reverse Automatic Braking (RAB) Indicators | Indicates that the system has been switched off. | |
| Reverse Automatic Braking (RAB) Indicators | Indicates that the system has been switched off. | |
 | Start/Stop System Function and Trouble Indicators | A problem with the Start/Stop system. |
 | Start/Stop System Function and Trouble Indicators | A problem with the Start/Stop system. |
 | Start/Stop System Function and Trouble Indicators | A problem with the Start/Stop system. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
| EV Mode Operation Indicators | Indicates that intelligent mode is selected, where battery life is automatically maximized. | |
| EV Mode Operation Indicators | Indicates that sport mode is chosen, providing increased performance and leaving battery life in the driver’s hands. | |
 | Low Speed, Grade and Terrain Assist Indicator | |
 | Low Speed, Grade and Terrain Assist Indicator | A problem with the Hill Start Assist system. |
 | Power and Sport Mode Indicator | A transmission ring gear. |
 | Electronic Power Control Indicator | Problem is detected in the engine electronics |
 | Electronic Power Control Indicator | Problem is detected in the engine electronics |
| EV Charging Indicator | The vehicle’s main battery is being charged and will turn off when it is fully charged. | |
 | Hybrid Battery Overheat Indicator | Illuminate if the temperature of the inverter with converter assembly is high. |
 | Remote Charge Timer Setting Indicator | The remote charge timer has been scheduled. |
 | Active, Adaptive and Cornering Light Malfunction | |
 | Active, Adaptive and Cornering Light Malfunction | |
 | Active, Adaptive and Cornering Light Malfunction | |
 | Lamp Out Indicator Symbol | One or more of the headlamp bulbs or other bulbs is burned out or malfunctioning |
 | Lamp Out Indicator Symbol | One or more of the headlamp bulbs or other bulbs is burned out or malfunctioning |
 | Lamp Out Indicator Symbol | The problem is with a low (dipped) beam light. |
 | Headlamp Leveling System Warning | Indicates a problem with the system. The vehicle should be taken to your dealer or authorized service center. |
 | Headlamp Leveling System Warning | Indicates a problem with the system. The vehicle should be taken to your dealer or authorized service center. |
 | Automatic Headlight Dimmer or Malfunction Indicator | Continue to function in high or low beam, but they will need to be cycled manually. |
 | Automatic Headlight Dimmer or Malfunction Indicator | Use as an Automatic Wiper Fault Indicator |
 | Rear Fog Lamp Indicator | When the lamps are actually on |
READ MORE: Diehard Battery Charger: 5 Best Of 2021 (Review and Buying Guide)
Green Indicator Lights
| Dashboard warning light | Name | Message |
|---|---|---|
 | Security and Immobilizer System Indicator | The ignition switch is locked and will need the proper transponder-equipped key fob to start or re-start. Flash when the vehicle is immobilized. |
 | Keyless Ignition Detection Indicator | Indicate the presence of an electronic key in a push button or, ironically, keyless start, or keyless ignition, vehicle. |
 | Traction and Active Traction Control Indicators | Indicate that the system has been activated and doing its job to maintain traction in slippery conditions |
 | Traction and Active Traction Control Indicators | Indicate that the system has been activated and doing its job to maintain traction in slippery conditions |
 | Traction and Active Traction Control Indicators | Indicate that the system has been activated and doing its job to maintain traction in slippery conditions |
| Driver Monitoring System Indicators | Indicates that the system is turned off | |
 | Lane Departure Warning Indicator | The system is turned off |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Cruise or Speed Control Text Indicators | The cruise control is engaged. It is perfectly straightforward, as opposed to the two image symbols below that are now often used in its place. |
 | Cruise or Speed Control Text Indicators | The cruise control is engaged. It is perfectly straightforward, as opposed to the two image symbols below that are now often used in its place. |
 | Cruise or Speed Control Text Indicators | A speed is set |
 | Cruise or Speed Control Text Indicators | The cruise control is engaged. It is perfectly straightforward, as opposed to the two image symbols below that are now often used in its place. |
| EV Mode Operation Indicators | Will be lit when this choice has been made by the driver. | |
| EV Mode Operation Indicators | Will be lit when this choice has been made by the driver. | |
| EV Mode Operation Indicators | Will be lit when this choice has been made by the driver. | |
| EV Mode Operation Indicators | Will be lit when this choice has been made by the driver. | |
| EV Mode Operation Indicators | Indicates that the vehicle is being driven as an electric vehicle only | |
| EV Mode Operation Indicators | EV mode and the high voltage battery is being saved for a more useful and economical time | |
 | Low Speed, Grade and Terrain Assist Indicator | The system is activated. |
 | Low Speed, Grade and Terrain Assist Indicator | The system is activated. |
 | Low Speed, Grade and Terrain Assist Indicator | |
 | Low Speed, Grade and Terrain Assist Indicator | |
 | Power and Sport Mode Indicator | A transmission ring gear. |
 | Hybrid Ready Indicator | A hybrid vehicle can move. |
 | Hybrid Ready Indicator | A hybrid vehicle can move. |
 | Hybrid Ready Indicator | A hybrid vehicle can move. |
| EV Charging Indicator | Illuminated or blinking while the vehicle’s main battery is being charged and will turn off when it is fully charged. | |
| EV Charging Indicator | The vehicle is not driven away while it is still plugged in. | |
 | Lamp Out Indicator | One or more of the headlamp bulbs or other bulbs is burned out or malfunctioning |
 | Automatic Headlight Dimmer or Malfunction Indicator | Indicates that the high beams are on and that the system will automatically (AUTO or A) switch between the low and high headlight beams on the automobile depending on whether or not sensors detect oncoming vehicle head lights in the distance. |
 | Automatic Headlight Dimmer or Malfunction Indicator | Indicates that the high beams are on and that the system will automatically (AUTO or A) switch between the low and high headlight beams on the automobile depending on whether or not sensors detect oncoming vehicle head lights in the distance. |
 | Automatic Headlight Dimmer or Malfunction Indicator | Indicates that the high beams are on and that the system will automatically (AUTO or A) switch between the low and high headlight beams on the automobile depending on whether or not sensors detect oncoming vehicle head lights in the distance. |
 | Park Lamp or Tail Light (Canada) Indicator | All the lights, except the headlights, are in use. |
 | Fog Lamp Indicator | The fog lamps are activated. |
 | Turn Signal Indicator | |
 | Low Beam On indicator |
Blue Indicator Lights
| Dashboard warning light | Name | Message |
|---|---|---|
 | Temperature Warning Indicator | Indicates that the coolant temperature is below what is needed for optimum performance. |
 | Frost or Cold Warning or Snow Mode Indicator | Some charge in the main EV battery may be lost or unavailable due to cold weather. The owners manual will offer methods for warming the battery. |
 | Remote Charge Timer Setting Indicator | The remote charge timer has been scheduled. |
 | Automatic Headlight Dimmer or Malfunction Indicator | The high beams are on and that the system will automatically (AUTO or A) switch between the low and high headlight beams on the automobile depending on whether or not sensors detect oncoming vehicle head lights in the distance. |
 | Automatic Headlight Dimmer or Malfunction Indicator | The high beams are on and that the system will automatically (AUTO or A) switch between the low and high headlight beams on the automobile depending on whether or not sensors detect oncoming vehicle head lights in the distance. |
 | High or Low Beam on Indicators | The light is active only when the high beams are active (turned on) and has been a standard in vehicles for decades. |
 | High or Low Beam on Indicators | The light is active only when the high beams are active (turned on) and has been a standard in vehicles for decades. |
 | Automatic Headlight Dimmer or Malfunction Indicator | The auto high beam system on |
White/Grey Indicator Lights
| Dashboard warning light | Name | Message |
|---|---|---|
 | Master Warning Light Indicator | Alert the driver to look for a message in the information center, but the message will not involve a serious drivability issue. |
 | Brake Override System Indicator | If a buzzer is not heard, the brake override system is operating. It turned off by releasing the accelerator pedal and stepping on the brake pedal. |
 | Tire Pressure Monitoring System Indicator | Illuminates to confirm that the load setting is selected. |
 | Electric Side Step or Auto Running Board Indicator | Indicates that the running boards have not extended in automatic mode. |
 | Blind Spot Warning or Monitoring System | The system is unavailable, likely because the sensors are dirty |
 | Blind Spot Warning or Monitoring System | The system is unavailable, likely because the sensors are dirty |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane.The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane.The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane.The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Lane Departure Warning Indicators | The vehicle is traveling close to either the left or the right of the traveling lane.The vehicle is traveling close to either the left or the right of the traveling lane. |
 | Start/Stop System Function and Trouble Indicators | If a problem with the system occurs, the vehicle can be operated normally. |
 | Start/Stop System Function and Trouble Indicators | The engine is ready to restart |
 | Start/Stop System Function and Trouble Indicators | Indicates the Start/Stop system is turned off |
 | Low Speed, Grade and Terrain Assist Indicator | Indicates a problem with the system, which will be spelled out in text on the screen. |
 | Extended Range EV Mode Indicators | A trip is expected to use all of the high-voltage battery’s charge. Using Hold Mode at higher, highway speeds maximizes both EV miles and fuel efficiency. |
 | Extended Range EV Mode Indicators | When steep grades or mountainous terrain are expected. The mode maintains a reserve electrical charge of the high voltage battery to provide better grade climbing performance, but the vehicle will have less responsive acceleration |
| EV Charging Indicator | The vehicle is not driven away while it is still plugged in. | |
| EV Charging Indicator | When in Save mode, the vehicle drives in a way that maintains the charge level of the high voltage battery | |
 | Automatic Headlight Dimmer or Malfunction Indicator | The high beam system off. The park lights are on |
 | Automatic Headlight Dimmer or Malfunction Indicator | The high beam system off. The park lights are on |
Conclusion
The Subaru dashboard lights enhance your driving experience and safety while on the road. For warning symbols and red lights that require immediate attention, act as necessary. Take your vehicle to the mechanic for repair. There may be more symbols that we have not covered in this article. So, you need to check your vehicle manual to familiarize yourself with all the light indicators on your vehicle.
READ MORE: Car Dashboard Symbols: What You Should Know
